Mono carton, corrugated shipper or rigid gift box — structure settled first, artwork second, because a beautiful panel on the wrong flap is wasted ink.
Pick a box
A reverse tuck: the top flap tucks from the front and the bottom from the back, which lets the blanks nest tightly on the press sheet and waste less board than a straight tuck. The glue lap runs 15–18 mm and gets pasted under the back panel — anything printed on it disappears, so nothing important goes there.
A regular slotted carton. Every flap is the same depth — half the box width — so the outer pair meets exactly down the centre. The inner pair, hinged to the narrow panels, closes underneath and leaves a gap. Flutes must run top to bottom: turn them sideways and the box crushes under its own stack.
Two separate pieces — a base, and a lid that sits over it. The printed sheet wraps the board and turns in around every edge, so the artwork needs extra margin on all sides. The lid is a couple of millimetres larger than the base so it lifts off cleanly.
The cheapest way to look expensive: an unprinted or lightly printed tray with a printed band sliding over it. A repeat product only needs a new sleeve, not a new box, which is why subscription packs use it.
What youget
Everything the box maker needs, in one handover.
- A dieline with cut, crease and glue drawn as separate layers
- Artwork on every panel, flap and tuck, in the right orientation
- Barcode, batch panel and statutory text placed where they stay readable
- Corrugation direction marked, so the box does not bow in a stack
- A made-up 3D visual for approval
- Files the box maker can go to plate from directly
- The flat and the mockup together, so nobody has to imagine it
- Editable source for the size variants that always follow
What decides the design
Five structural facts that outrank any layout idea.
- Which panel faces the buyerOn a shelf it is the front. Inside a carton it is the top. On a courier pallet it is whichever side the label goes on. Design hardest for the one people actually see.
- The glue lapFifteen to eighteen millimetres of board that gets pasted underneath the back panel. Anything printed there is never seen again, so nothing important crosses it.
- Creases eat the artworkA steel rule pressed through board distorts whatever sits on the line. Type and logos get moved off every crease before the artwork is called final.
- Flute directionOn corrugated, flutes must run top to bottom. Turn them sideways and you get a box that crushes under its own stack, whatever the artwork looks like.
- The print method changes the artFlexo on brown corrugated cannot hold a soft gradient or fine photography. Bold line work survives it. We design for the press you are actually using.
- Carton board
- 250–350 gsm
- Glue lap
- 15–18 mm
- Bleed
- 3 mm all round
- Output
- CDR, AI, PDF
How a box gets designed
01
Structure
Box type, internal size and material, agreed before a single panel is drawn. This is where the cost is decided.
02
Dieline
Cut, crease and glue drawn on separate layers, so the box maker can read it at a glance instead of guessing.
03
Artwork
Every panel laid out on the dieline and checked against the folds, laps and creases it has to live with.
04
Mockup and files
A made-up 3D view for approval, then plate-ready files in the format your box maker asked for.
